Location:Home > Products > NISO,NIS,NISF End Suction Centrifugal Pump > NISO,NIS,NISF End Suction Centrifugal Pump
Flow rate: 3m³/h~1900m³/h
Head: 4m~160m
Temp: -15℃~+110℃
Voltage: 220V/380V
Max.Working pressure: 16 bar
Max.Inlet pressure: 6 bar
Max.Power: 250kW
Inlet and outlet diameter:
Inlet diameter: DN50~DN350
Oulet diameter: DN32~DN300
Water treatment systems
HVAC systems
District heating systems
Industrial cooling systems
Firefighting systems
Other pressure boosting systems
Stainless steel/Cast iron
